ABI DUPLOMAT 12 WITH BUFFED RUBBER

  • Suitable for zone 2 and 3 (inside)
  • Total mat height: 12 mm
  • Suitable for (heavy) rolling loads
  • Moisture absorption
  • Choice of 3 colours
  • Combination possible: single, double or triple (new!)

Product codes:

Gray: DUM-02

Black: DUM-12

Zebra: DUM-42





The ABI Duplomat is constructed from rubber profiles, integrated with synthetic fabric by the process of vulcanization. The buffed rubber profile protects against dirt and is able to absorb a large amount of moisture. After the vulcanization process, the rubber is brushed away on both sides of the profile, which makes the mat reversible and usable on both sides.



Maximize the cleaning effect and combine with double or triple buffed rubber!



Available in the colours: gray, black and zebra.

COLOURS

SPECIFICATIONS



Aluminium height

12 mm

Aluminium width

16 mm

Aluminium thickness

1,5 mm

Insert material

Vulcanized layered rubber strips with pre-coloured textile (colourfast).

Inset material hight

12 mm

Insert material width

15 mm

Profile connection

Galvanized steel cable bracket 2.5 mm

Standard aluminium

Brute

Optional aluminium

Anodization in 24 colours More information.

Optional inserts

Single, double or triple

Loadability

2.900 kg per 100 cm2

Fire load classification

Cfl-s1

Anti slip classification

R11

Weight

ca. 15 kg / m2

Total mat height

12 mm

INSERT OPTIONS


Buffed Rubber

Colours:

Gray

Black

Zebra (gray-black)

OPTIONAL ACCESSORIES

ANODIZATION

WELL FRAMES

T PROFILES

duplomat_12mm_dubbel_grijs_02

SAMPLE REQUEST

    If you would like more information or a sample product,
    please call us direct at +31 546 - 81 30 21,
    or fill in the request form below.
